MC-PAOX03 51309152-175 Output Processor (AO Module)

MC‑PAOX03（51309152‑175）
1、 Basic Information
Model: MC-PAOX03; Order number: 51309152-175
Brand: Honeywell
Series: TPS/TDC3000 DCS (old generation system)
Type: 8-channel analog output (AO) IOP module
Function: Digital quantity → 4-20mA/0-10V analog output, with HART
Status: Original EOL (discontinued), no new production; Market has inventory/second-hand
Alias: 51304672-150 (non CE version)

2、 Core parameters
Channel: 8 isolated analog outputs
Signal: 4-20mA (default)/0-10V optional
Accuracy: ± 0.05% FS, temperature drift ± 20ppm/℃
Load: 50mA continuous, 250mA peak
Response:<10ms
Communication: HART (supports intelligent valve positioner)
Isolation: 1500Vrms between channels
Power consumption: 12VDC @ 150mA
Temperature: 0-60 ℃
Adaptation: TPS/TDC3000 UCN network, requires FTA terminal board
3、 Life cycle and substitution
Production stoppage time: gradually EOL after 2010, complete shutdown after 2020
Official replacement: No direct replacement model available (system has been upgraded to PKS)
Compatible alternatives:
Same system spare parts: Find 51309152-175 brand new inventory/disassembly card parts
System Upgrade: Migration to Honeywell PKS C200/C300, using new AO cards such as TC-AOI08
