GE IS200EDISG1AAA Ex2100e Power Distribution Board

GE IS200EDISG1AA Ex2100e Power Distribution Board
Basic Product Information
Project information source
Brand General Electric (GE)
Model IS200EDISG1AA
Related model IS200EDISG1A
EX2100e series (belonging to GE Speedtronic Mark VIe series)
Product Type Excitation Power Distribution Board/Power Distribution Board
Origin: United States

Main functions
Core function: Used to supply power to other boards produced by GE
Power distribution: Connect customer AC and DC control power to system hardware
System application: used for vibration monitoring of turbines and other rotating equipment
Power input: Supports DC and AC power input
Power supply object: can supply power to other I/O boards, controllers, and bridge rectifier boards
technical parameters
Source of parameter values
Working temperature -30 to 65 degrees Celsius
11 switches (5 on the right, 5 at the bottom, and 1 without label)
52 female sockets (5 of which are 9-pin sockets located near PSM1, PSM2, PSC, PSAX1, and PSAX2)
Redundancy support supports single, double, and triple redundancy modes
System compatibility and communication
EX2100e system: belongs to the thyristor based digital control system EX2100e
DCS communication: Can be used in conjunction with EX2100 system and other DCS systems that use Ethernet Modbus protocol
High speed interface: Some versions support high-speed serial link interface
Maintenance and Precautions
Storage requirements: As an electrostatic sensitive component, direct contact should be avoided. It is recommended to store it in an anti-static box and wear anti-static gloves
Warranty service: Some second-hand refurbished products offer a 60 day or 1-year warranty
Maintenance service: can quickly test, diagnose and repair, provide refurbishment services (including replacement of aging components, TIL modification, reflow soldering, cleaning and rust prevention treatment)
Application scenarios
Turbine Control: Excitation Power Distribution Component in GE Speedtronic Mark VIe System
Wind turbines: alternative energy applications that can be used for wind turbines
Rotating equipment: used for vibration monitoring of turbines and other rotating equipment
