ABB CP800 Communication Control Processor

ABB CP800 (Symphony Plus HPC800 System Communication Processor)
CP800 is a dedicated communication control processor for ABB Symphony Plus (HPC800) DCS system. Its core is responsible for PN800 factory network communication, multi protocol gateway, and system data forwarding. It is a standard communication module for HPC800 controller and will still be available for sale in 2026.

1、 Basic Information
Model: CP800 (complete material number: CP800, without suffix)
Brand: ABB (Switzerland)
System: Symphony Plus (HPC800) DCS
Positioning: Communication processor/gateway module (non main CPU, main CPU is HPC800)
Status: On sale (May 22, 2026), new system standard, preferred for expansion of old system
Installation: DIN rail installation, combined with HPC800 in the same slot position
Certification: CE, UL, RoHS
2、 Core hardware specifications (official)
Processor: 2 x 32-bit ColdFire, 256 MHz (shared with HPC800)
Memory: 64 MB RAM; ROM 4 MB
Power supply: 24 VDC ± 10% (system bus power supply, no additional power required)
Power consumption: approximately 10 W (typical)
Dimensions: 170.18 × 73.66 × 243.84 mm (width × height × depth)
Weight: Approximately 0.99 kg
Working temperature: 0 ° C~+70 ° C; Storage: -20 ° C~+70 ° C
Protection: IP30 (for use inside industrial control cabinets)
3、 Interface and Communication Capability (Core)
1) Fixed interface
PN800 (Plant Network): 1 × 10/100 Mbps Ethernet (dedicated factory bus, HPC800 system intranet)
Universal Ethernet: 1 × 10/100 Mbps Ethernet (external network/third-party devices)
Serial port: 1 × RS-232/485 (optional protocol)
2) Supporting protocols (multi protocol gateway)
Ethernet: Modbus TCP, PROFINET, EtherNet/IP, OPC UA
Fieldbus: Profibus DP, FF HART, Modbus RTU (serial port)
System bus: PN800 (proprietary to Symphony Plus)
4、 Core functions
System Communication Hub: HPC800 Main CPU ↔ CP800 ↔ On site equipment/third-party systems, forwarding real-time data, alarms, and configurations
Multi protocol gateway: achieving cross protocol interoperability between Symphony Plus and PLC, HMI, SCADA, and instruments
Data processing and forwarding: caching, filtering, protocol conversion, reducing the load on the main CPU
Redundancy support: Supports dual CP800 redundancy configuration, seamless switching, and improves system availability
Diagnosis and maintenance: LED status light, S+Engineering tool online diagnosis, firmware upgrade
5、 Typical application scenarios
Industry: Electric Power (Thermal Power/Hydroelectric/Nuclear Power), Oil and Gas, Chemical Industry, Water Treatment, Metallurgy
System: ABB Symphony Plus (HPC800) DCS project
Function: Connect DCS with third-party PLCs (such as Siemens, Rockwell) HMI、SCADA、 Intelligent instruments, building an integrated control network for the entire factory
6、 Relationship with HPC800 (Key Differences)
HPC800: Main Controller (CPU), responsible for logic control, computation, and I/O processing
CP800: Communication coprocessor, responsible for external/internal communication, protocol conversion, and data forwarding
Combination: HPC800+CP800=Complete Symphony Plus Controller Node
