TRICONEX 3009X Triple Modular Redundancy Control (TMR)

TRICONEX 3009X Triple Modular Redundant Control (TMR) System

Product Overview:
The TriconeX 3009X is a high-performance Triple Redundancy (TMR) controller in the Triconex series of Safety Instrumented Systems (SIS) under Honeywell, designed specifically for safety control of critical industrial processes. The system adopts a triple module redundant architecture, which achieves redundant control and voting functions through three independent processor channels, significantly improving the reliability and security of the system.

Main features and advantages
Triple Modular Redundancy (TMR) architecture: It includes three completely independent processor channels and achieves output synchronization through a “two out of three” voting mechanism to ensure that a single fault will not cause system failure. It complies with international safety standards such as IEC 61508 and IEC 61511 and is suitable for SIL 3 safety application scenarios.
High performance processing capability: With a clock speed of up to 1.2 GHz, equipped with 1GB DDR3 memory and 16GB storage space, it supports complex logical operations and high-speed data processing. A single controller can manage over 750000 TMR I/O channels.
High reliability design: All metal casing, supporting a working temperature range of -20 ° C to 55 ° C, suitable for harsh industrial environments; Built in hardware fault detection and self diagnosis functions, supporting hot swappable modules.
Rich communication interfaces: integrated with 4 Ethernet ports, 2 CAN buses, and 2 RS-485 interfaces, supporting protocols such as Modbus TCP/IP and OPC UA, seamlessly integrated with DCS, SCADA, HMI, and other systems.
Powerful safety features: Supports motion control below 16 axes, integrates fire and gas (F&G) functions such as flame detection and gas leak detection, provides sequence of events (SOE) recording function, and has a time resolution of 1 millisecond.
Flexible I/O expansion capability: Supports up to 118 I/O modules, and can flexibly configure input and output points according to project requirements.

technical specifications

Product Model: TRICONEX 3009X
Triple Modular Redundancy (TMR) in Processor Architecture
Safety Integrity Level SIL 3 (compliant with IEC 61508)
Input voltage 18-32V DC
Working temperature range -20 ° C to+55 ° C
Storage temperature range -40 ° C to+85 ° C
Communication interfaces such as Ethernet, Modbus, Profibus, etc
I/O expansion capability supports up to 118 I/O modules
Certification standards T Ü V, IEC 61508, ISA 84.01

Application scenarios
The TRICONEX 3009X is widely used in the following industrial fields:
Oil and gas: Refinery emergency shutdown system (ESD), natural gas processing plant safety interlock.
Chemical industry: reactor overheating and overpressure protection, toxic gas leakage detection.
Power industry: safety level control system for nuclear power plants, overspeed protection for steam turbines in thermal power plants.
Offshore platforms: Fire and gas detection and fire protection linkage, drilling platform safety control.

Related products

TRICONEX 3664: Controller modules of other models.
TRICONEX 4351B: Controller modules of other models.
TRICONEX 3503E: Controller modules of other models.
TRICONEX 3721: Controller modules of other models.
These modules, together with the TRICONEX 3009X Triple Modular Redundant Control (TMR) system, form a complete industrial safety control system suitable for safety critical applications in various high-risk industries.
