ABB 3BHE046836R0101 GFD563A101 Ethernet Port Module

ABB 3BHE046836R0101 GFD563A101 Ethernet Port Module

product overview
ABB 3BHE046836R0101 GFD563A101 is a high-performance Ethernet port module designed specifically for industrial automation and power systems.

It can provide Ethernet connectivity for ABB controllers or systems, ensuring efficient data transmission between devices.

technical specifications

Power supply voltage 24V DC
Power consumption 10W
Ethernet standard IEEE 802.3
Data rate 10/100 Mbps
Connector type RJ45
Supported protocols TCP/IP, UDP, Modbus TCP, Profinet
Working temperature range -20 ° C to+60 ° C
Storage temperature range -40 ° C to+85 ° C
Humidity 5% to 95% (no condensation)
Installation method: DIN rail or panel installation
Dimensions 100mm × 80mm × 50mm
Weight 2.2 kilograms
Certification CE, UL, CUL

Main features and advantages
Efficient communication: Following the IEEE 802.3 Ethernet standard, supporting 10/100 Mbps data rates, ensuring fast and reliable data transmission.
Wide protocol support: Supports multiple industrial protocols such as TCP/IP, UDP, Modbus TCP, and Profinet, facilitating seamless integration with various industrial devices and systems.
Flexible installation options: Supports DIN rail installation and panel installation, adapting to different installation environments.
Strong environmental adaptability: wide working temperature range (-20 ° C to+60 ° C), wide storage temperature range (-40 ° C to+85 ° C), capable of stable operation in harsh industrial environments.
Low power design: With a power consumption of only 10W, it is suitable for long-term continuous operation.
Compact design: Small size (100mm × 80mm × 50mm), light weight (0.22 kg), easy to install and integrate.

application area
Industrial automation: used in factory automation control systems, especially for transmitting data and achieving real-time control.
Power system: used for excitation device control unit to ensure stable operation of the generator.
Robot system: Provides stable network connectivity in robot control and data exchange.
Energy management: used for monitoring and control in energy systems, such as substations and distribution systems.
Transportation: Used for real-time guarantee of railway signal system.

Related products
ABB 3BHE046837R0101: A more advanced version with enhanced data processing capabilities, suitable for high traffic industrial networks that require faster data processing.
ABB 3BHE046835R0101: An early model with basic Ethernet connectivity, typically used in less complex and cost-effective industrial environments.
ABB 810-001: Communication Gateway Module, compatible with 3BHE046836R0101 GFD563A101 to expand network coverage and connect to other non Ethernet devices.
ABB 575-002: Power module ensures stable power supply for 3BHE046836R0101 GFD563A101 and other connected devices.
ABB 920-003: Diagnostic module, can be integrated with 3BHE046836R0101 GFD563A101, providing deeper network monitoring and troubleshooting functions.
